Writing a new Extractor for PHPoAuthUserData

In my previous post I introduced my latest library PHPoAuthUserData that allows to abstract the process of
extracting user profile data from various OAuth providers (Facebook, Twitter, Linkedin, etc).

The library still need a lot of work, especially to write the logic to extract data from all the services available in the parent OAuth library.

At the moment the library supports only the most common OAuth providers. I would be glad to support all the following services:

Amazon, BitBucket, BitLy, Box, Dailymotion, Dropbox, Etsy, FitBit, Flickr, Foursquare, GitHub, Google, Heroku, Mailchimp, Microsoft, PayPal, Reddit, RunKeeper, SoundCloud, Tumblr, Vkontakte, Yammer.

So that's a lot of work! And yes, of course I would be glad to share it with someone interested in using the library.

This article illustrates how to add support for a new service by writing a dedicate extractor class. It's really simple so stick with me and you will be able to submit your pull request in minutes!

Extractors defines the logic to request information to a given service API and to normalize the received data according to a common interface.
The most basic way to define an extractor is to write a class that implements the ExtractorInterface (that is pretty self-explanatory).

You could extend the class Extractor that implements most of the needed code to get you started. Anyway, extractors should really extend the class LazyExtractor where possible
because this class acts as a boilerplate to define highly optimized extractors. It easily allows you to implement extractors that lazy loads data (perform requests only when needed to) and caches data (does not make the same request more than once and avoids normalizing the same data more than once). Everything is done behind the scenes, so you'll need to focus only on methods that define how to make
requests and how to normalize data.

To understand how to write a new extractor by adopting the LazyExtractor we need to clarify some concepts:

  • Supported fields: an array of the fields that can be extracted (you should use field constants from the ExtractorInterface).
  • Loaders: methods whose responsibility is to trigger the proper request to the OAuth provider endpoint to load a specific set of raw data. Generally you need to define a loader for each block of information that could be retrieved from the endpoint. this methods must have the suffix Loader in their name. Most of the service will allow you to retrieve all the user data with a single request, so, in this cases, you would have only a single loader method (eg: profileLoader).
  • Normalizers: methods that accept raw data (the one previously fetched by some loader method) and uses it to extract the value for a given field. Usually you have a normalizer for each supported field. Normalizers methods must have the suffix Normalizer (eg. uniqueIdNormalizer or descriptionNormalizer).
  • LoadersMap: an array that associates supported fields (keys) to loaders methods (values). Loaders methods must be referenced without the Loader suffix. Most of the time, if you have only the profileLoader loader you will have an array with all fields mapping to the string profile.
  • NormalizersMap: an array that associates supported fields (keys) to the related normalizer methods (values). Normalizers methods must be referenced without the Normalizer suffix. It's highly suggested to use the same name of the field for its related normalizer, so, most of the time, you will end up by having an array that maps field constants to the same field constant (eg. array(self::FIELD_UNIQUE_ID => self::FIELD_UNIQUE_ID)) for every supported field.

Once you defined Supported Fields, Loaders, Normalizers, Loaders Map and Normalizers Map from within your new extractor class you must
wire them to the underlying logic by passing them to the parent constructor. So if you defined methods such as getSupportedField, getLoadersMap and getNormalizersMap
you will end up with a constructor like this:

public function __construct()
{
    parent::__construct(
        self::getLoadersMap(),
        self::getNormalizersMap(),
        self::getSupportedFields()
    );
}

But let's see how I built the Instagram extractor to have a better understanding on the whole process.

Writing the Instagram extractor

First of all I had a look on a bit of documentation to find out what kind of data can be extracted from Instagram users.

So I discovered that the request to retrieve information about the user is: /users/self and its response is a json object that looks like the following:

{
  "meta":  {
    "code": 200
  },
  "data":  {
    "username": "johnnydonny",
    "bio": "A life on the edge",
    "website": "http://blog.johnnydonny.com",
    "profile_picture": "http://images.ak.instagram.com/profiles/profile_weird_numbers.jpg",
    "full_name": "John Doe",
    "counts":  {
      "media": 131,
      "followed_by": 80,
      "follows": 64
    },
    "id": "1111222333"
  }
}

So I understood wich fields can be mapped and started writing the Instagram class under the OAuth\UserData\Extractor namespace.

<?php

namespace OAuth\UserData\Extractor;

class Instagram extends LazyExtractor
{
    //...
}

First of all I wrote the method profileLoader and added a class constant that defines the url of the request.

const REQUEST_PROFILE = '/users/self';

protected function profileLoader()
{
    return json_decode($this->service->request(self::REQUEST_PROFILE), true);
}

Each extractor has access to the property $this->service that is an instance of the specific OAuth service from the parent library (OAuth\OAuth2\Service\Instagram) in this case. With this instance you can easily make request to the provider API endpoint.

Then I added the getSupportedFields method:

protected static function getSupportedFields()
{
    return array(
        self::FIELD_UNIQUE_ID,
        self::FIELD_USERNAME,
        self::FIELD_FULL_NAME,
        self::FIELD_FIRST_NAME,
        self::FIELD_LAST_NAME,
        self::FIELD_DESCRIPTION,
        self::FIELD_WEBSITES,
        self::FIELD_IMAGE_URL,
        self::FIELD_PROFILE_URL,
        self::FIELD_EXTRA
    );
}

The fields first_name, last_name and profile_url are not directly available on the json response but are easy to reconstruct by using the full_name and username fields.

Than I started writing all the normalizer methods to map the raw data to the respective supported fields:

protected function uniqueIdNormalizer($data)
{
    return isset($data['data']['id']) ? $data['data']['id'] : null;
}

protected function usernameNormalizer($data)
{
    return isset($data['data']['username']) ? $data['data']['username'] : null;
}

protected function fullNameNormalizer($data)
{
    return isset($data['data']['full_name']) ? $data['data']['full_name'] : null;
}

protected function firstNameNormalizer()
{
    $fullName = $this->getField(self::FIELD_FULL_NAME);
    if ($fullName) {
        $names = explode(' ', $fullName);

        return $names[0];
    }

    return null;
}

protected function lastNameNormalizer()
{
    $fullName = $this->getField(self::FIELD_FULL_NAME);
    if ($fullName) {
        $names = explode(' ', $fullName);

            return $names[sizeof($names) - 1];
    }

    return null;
}

protected function descriptionNormalizer($data)
{
    return isset($data['data']['bio']) ? $data['data']['bio'] : null;
}

protected function websitesNormalizer($data)
{
    $websites = array();
    if (isset($data['data']['website'])) {
        $websites[] = $data['data']['website'];
    }

    return $websites;
}

protected function profileUrlNormalizer()
{
    $username = $this->getField(self::FIELD_USERNAME);

    if (null !== $username) {
        return sprintf('http://instagram.com/%s', $username);
    }

    return null;
}

protected function imageUrlNormalizer($data)
{
    return isset($data['data']['profile_picture']) ? $data['data']['profile_picture'] : null;
}

protected function extraNormalizer($data)
{
    return ArrayUtils::removeKeys($data['data'], array(
            'id',
            'username',
            'full_name',
            'website',
            'profile_picture',
            'bio',
    ));
}

Notice that each normalizer must return null if the field is not defined. That's a best pratice to follow for safety.

Also notice that the extraNormalizer method has the purpose to keep track of all the fields that could not be mapped to the ExtractorInterface fields. So we use the OAuth\UserData\Utils\ArrayUtils::removeKeys method to simply remove already mapped data.

Finally we need to wire our profileLoader method and all our normalizers methods in the constructor:

public function __construct()
{
    parent::__construct(
        self::getDefaultLoadersMap(),
        self::getDefaultNormalizersMap(),
        self::getSupportedFields()
    );
}

The methods self::getDefaultLoadersMap and self::getDefaultNormalizersMap are convenience methods defined in the LazyExtractor class that defines respectively a loaders map and a normalizers map that are good in most of the cases.

That's all. To see the complete class have a look here.

Important note: if you are willing to submit a pull request to integrate a new extractor be sure to follow PSR-2 code style and to add a dedicated test case. Have a look at the InstagramTest class to understand how to do it.
