The hidden design compromises of Docker layers

The other week I was looking into some Docker shenanigans, specifically SOCI (Seekable OCI). In a nutshell, SOCI builds an index of the contents of your container image layers, so that a container can start before the whole image has been downloaded, and the files it needs are lazily fetched as they are accessed. (Spoiler: there will probably be an AWS Bites episode about SOCI soon, so stay tuned there if you are curious.)

While reading about compressed layers, indexes and lazy loading, I started poking at my own understanding of Docker images. And I didn’t love what I found.

I have been using Docker for years. I could happily tell you that “an image is made of a stack of immutable layers” and I would probably even draw you a nice diagram with some boxes stacked on top of each other. But if you asked me what those layers actually contain, my answer would get hand-wavy pretty quickly.

One question in particular got stuck in my head:

If Docker layers are basically tar archives applied on top of one another to produce a filesystem, how can one layer delete a file created by a previous layer?

Think about it for a second. A tar archive can say “here’s a file called foo”. A later tar archive can say “here’s another version of foo”. But tar doesn’t have a generic operation that says “please delete foo from the archive that came before me”.

And, of course, once I started asking that question, I had to find out.

Spoiler: the answer involves magic file names, “opaque” directories, a whole namespace of perfectly valid Linux file names that you can’t faithfully put in a container image, and a Docker image that behaves differently after you export it and import it again. Let’s jump down the rabbit hole together! 🐇

Tar: a brilliant, boring choice

Before we start digging, let me share a thought that has been bouncing around my head since I started this investigation.

Using tar as the foundation for image layers feels, in retrospect, like a brilliantly pragmatic engineering choice. Tar is:

• ubiquitous: every Unix-like system has tooling for it;
• simple: it’s a sequence of entries, nothing fancy;
• streamable: you can process it as it arrives, without random access;
• extremely well understood: it has been around since the late 70s;
• decent at describing Unix filesystems: permissions, ownership, timestamps, symlinks, and more.

But tar was designed to describe a bunch of files. It was not designed to describe a diff between two filesystems.

My feeling (and I want to be clear that this is my interpretation, not a historical account of why the Docker and OCI folks made these choices) is that this is what often happens when you reuse an existing technology for something slightly beyond its original purpose: it works great, until you hit an impedance mismatch. And then you need a convention, or a workaround, to bridge the gap.

Whiteouts, which we are about to meet, feel like exactly one of those moments.

By the end of this article, I’d love for you to tell me whether you think this is an elegant extension of tar or a slightly hacky workaround. I can see arguments for both.

So what is a Docker image layer, really?

Let’s start from something familiar:

FROM alpine:3.20

RUN apk add --no-cache curl

COPY app /app

RUN echo "hello" > /app/hello.txt

You have probably heard that “every Dockerfile instruction creates a layer”. That’s not quite right. The steps that change the filesystem (like RUN, COPY and ADD) produce filesystem changes that end up as image layers, while other instructions (like ENV, CMD, EXPOSE or LABEL) only tweak the image configuration.

In fact, a container image is more than just filesystem data. Roughly speaking, it’s made of:

• a manifest, which lists all the pieces that make up the image;
• an image configuration, with things like environment variables, the default command, the working directory, and so on;
• an ordered list of filesystem layers.

For this article, we mostly care about the last one: the filesystem layers.

For our Dockerfile, the stack of layers looks something like this:

Layer 3   add /app/hello.txt
Layer 2   add /app/*
Layer 1   install curl (and whatever apk touches)
Layer 0   Alpine base filesystem
             ↓
         merged view

The order matters. When a container runs, it doesn’t see a folder called “Layer 0”, another folder called “Layer 1” and so on. It sees the combined result of applying all the layers, one after the other, in order:

layer 0
   +
layer 1
   +
layer 2
   +
layer 3
   =
filesystem visible to the container

A quick note on vocabulary: since what really matters is the order in which layers are applied, in this article I’ll talk about earlier and later layers. Elsewhere (including the OCI spec and the OverlayFS docs) you’ll often see them called lower and upper layers, because they’re usually drawn as a stack. Same thing, different metaphor.

The other important property is that layers are immutable. Once a layer is created, it never changes. A new layer doesn’t edit a previous one: it describes another set of changes that gets applied after the previous ones.

This immutability is what makes a lot of the Docker magic possible:

• caching: if nothing changed, a build step can reuse the existing layer;
• sharing: 20 images based on alpine:3.20 can share the same base layer, on disk and over the network;
• content-addressed distribution: each layer is identified by the hash of its content, so registries and clients can tell whether they already have it.

OK, so far nothing new. But what’s inside one of these layers?

A layer is a filesystem changeset

Here’s where we need to be a little more precise than “a layer is a tar archive”.

The OCI Image Specification (the standard that describes the format of container images, which Docker images follow these days) calls a layer an image layer filesystem changeset. When an image is distributed (for instance, when you push it to or pull it from a registry), each layer is represented as a tar-based changeset. The tar payload is usually compressed too, most commonly with gzip or zstd (the spec defines media types such as application/vnd.oci.image.layer.v1.tar+gzip and application/vnd.oci.image.layer.v1.tar+zstd).

This doesn’t mean that Docker keeps a pile of .tar.gz files around and extracts them every time you start a container. Locally, the storage driver (for example, overlay2) keeps each layer as an extracted directory and uses a union filesystem to stack them. The tar representation is how layers are serialized and moved around. Keep this distinction in mind, because it’s going to come back to bite us later!

From now on, I’ll casually talk about “the layer tar”, but remember: that’s the serialized form, not necessarily what’s sitting on your disk.

The key idea: A layer is not a complete filesystem. It is a filesystem changeset that only has meaning when applied after the layers that came before it.

So what does a changeset contain? According to the OCI spec, there are three types of change:

• Additions
• Modifications
• Removals

Additions and modifications are easy to represent in tar. Removals are the interesting one. But let’s take things in order.

A tar archive is basically a sequential stream of entries. Each entry has a header with the path and some metadata, followed by the file contents (where applicable). Among the metadata that a layer entry carries, you’ll find:

• the permissions (mode);
• the owner (UID and GID);
• the modification time;
• the link target, for symlinks and hard links;
• extended attributes, where supported.

So a layer tar might conceptually look like this:

app/
app/index.js
app/config.json
etc/my-app.conf

When this changeset is applied on top of the previous filesystem:

• paths that don’t exist yet are added;
• paths that already exist are replaced;
• directories that exist on both sides merge into one.

The spec actually makes a point of saying that layer changesets are applied, rather than simply extracted as tar archives. This sounds like a pedantic distinction right now, but hold that thought.

Adding files is the easy part

Let’s say Layer A contains:

/app/
  index.js

And Layer B contains:

/app/
  config.json

The merged filesystem will be:

/app/
  index.js
  config.json

At the tar level, Layer B simply contains an entry for app/config.json (and, typically, one for the parent directory app/). No special trick needed. Tar already knows how to say “here’s a file”.

The same goes for directories. When a directory exists in an earlier layer and a directory with the same path shows up in a later layer, their contents compose into a single directory in the final filesystem. (If you are wondering: the spec says that the later directory’s attributes, like permissions and ownership, replace those of the existing one. The children are merged, not replaced.)

So far so good. This sounds simple enough, right?

Changing a file doesn’t change the old layer

What about modifying an existing file?

Let’s say Layer 1 contains /app/config.json:

{ "debug": false }

And Layer 2 contains another /app/config.json:

{ "debug": true }

The container will see the Layer 2 version, with debug set to true.

This is how a modification is represented: the new layer simply ships a new, complete version of the file. The OCI spec is pretty explicit about it: “Additions and Modifications are represented the same in the changeset tar archive”. There’s no binary patch, no “change byte 12 from f to t”. Changed one character in a 200 MB file? Congratulations, your new layer contains a brand new 200 MB file! 🎉

And, crucially, the original version of the file is still there, inside Layer 1. The newer layer doesn’t touch the bytes of the older one (layers are immutable, remember?). It just provides an entry that takes precedence.

This has a practical consequence that you might have stumbled into:

RUN curl -o /tmp/huge-file.tar https://example.com/huge-file.tar
RUN rm /tmp/huge-file.tar

The second RUN removes the file from the final filesystem, but it doesn’t magically shrink the layer created by the first RUN. That layer is immutable and it still contains the whole file. This is why “I deleted the giant file in the next RUN instruction” doesn’t save you from shipping the giant file’s layer (and why you often see downloads, extraction and cleanup chained in a single RUN, or multi-stage builds).

But wait a second… we just said that the second RUN “removes the file”. What does that layer actually contain?

How do you delete a file from a layer?

This is the question that sent me down the rabbit hole in the first place.

Let’s try to recap what we know so far and see if we can come up with some kind of educated guess…

Let’s say Layer 1 contains:

/app/
  index.js
  old-config.json

And we want the result after Layer 2 to be:

/app/
  index.js

What should Layer 2 contain?

• It can’t modify Layer 1, because layers are immutable.
• It can’t just “not mention” old-config.json, because absence in a layer simply means “this layer has no change for that path”. If absence meant deletion, every layer would have to list every single file in the filesystem to keep it alive, and we’d lose the whole point of layers.
• And tar has no “negative file”. There’s no entry type that means “the thing that used to be here, please make it go away”.

Take a moment to think about how you would solve this. If you were designing the format, what would you do?

Take your time, I’ll be here waiting…

Got an idea?

Great, now let’s see how OCI does it.

Meet the whiteout

To remove /app/old-config.json, the newer layer contains an entry called:

/app/.wh.old-config.json

That’s it. I swear, that’s the trick. 😅

The .wh. prefix (short for whiteout) means: “when applying this layer, remove the path from earlier layers whose name is whatever follows .wh.”.

Layer 1
/app/
  index.js
  old-config.json

Layer 2
/app/
  .wh.old-config.json

         ↓ apply layers

Result
/app/
  index.js

Note that .wh.old-config.json is present in the layer archive, but it is not supposed to become a regular file in the final filesystem. It’s an instruction encoded as a specially named tar entry. After the layer is applied:

• the earlier old-config.json is gone from the merged view;
• the whiteout itself is also hidden (the spec says: “Once a whiteout is applied, the whiteout itself MUST also be hidden”).

Now, here’s the part I find most interesting. Tar itself has no idea that .wh.old-config.json is special. As far as tar is concerned, it’s just a regular file with a weird name. In fact, the spec even says so: “regardless of the path being deleted, the whiteout file is a regular file in the archive”.

It’s the OCI consumer, the thing that applies the layer, that looks at the name and says: “Ah! You don’t actually want this file. You want me to remove old-config.json from an earlier layer.”

Whiteouts are not a tar feature. They are an OCI convention encoded using specially named tar entries.

So that’s what “applied, rather than simply extracted” means. If you just ran tar -xf on a layer, you would end up with a bunch of .wh.* files lying around, and nothing would be deleted.

So apparently we solved this one by inventing files that aren’t really files.

I’ll leave it to you to decide whether you think that’s elegant or hacky. It surely is clever, but otherwise I have mixed feelings myself.

Anyway, a couple more rules from the spec are worth knowing, because they’ll matter later:

• Whiteouts only apply to earlier layers. A whiteout can’t delete a file that was added in the same layer. Quoting the spec: “Files that are present in the same layer as a whiteout file can only be hidden by whiteout files in subsequent layers.”
• A .wh. entry with nothing after the prefix is invalid, and implementations “SHOULD return an error when encountering such an entry”.
• The spec describes a whiteout as an empty file. Keep this one in your back pocket too.

What about directories?

The same mechanism works for directories. If an earlier layer contains:

/app/cache/
  a
  b
  c

A following layer containing:

/app/.wh.cache

removes the entire cache directory, along with everything inside it.

Nice and consistent. But sometimes we want something slightly different.

There’s an even stranger whiteout

What if we don’t want to delete the directory, but we want to say: “keep this directory, but forget about everything it inherited from earlier layers”?

This can happen, for instance, when a build step deletes a directory and recreates it with completely new contents. The directory still exists, but none of the old children should show up.

One option is to add a whiteout for every single child. That works, but imagine you have a large build folder with hundreds or even thousands of child files or folders (yes, like a node_modules 😏), it wouldn’t be convenient to have to create a whiteout for each one of them, right?

In fact, OCI has a dedicated marker for this case, and it’s the weirdest file name in this whole article:

.wh..wh..opq

Yes, that’s .wh. twice, followed by .opq, which stands for opaque. An opaque whiteout inside a directory means: “for this directory, don’t merge in the children inherited from earlier layers”.

Let’s see an example to better understand this concept.

Suppose we have a directory called /node_modules in an earlier layer, with two subdirectories:

/node_modules/
  left-pad/
    index.js
  event-stream/
    index.js

Later layer:

/node_modules/
  .wh..wh..opq
  colors/
    index.js

Result:

/node_modules/
  colors/
    index.js

The /node_modules directory stays, the earlier left-pad and event-stream directories disappear, and the new colors directory from the same layer as the marker survives. The spec also clarifies that the opaque marker is processed before the other entries of that directory in the same layer, regardless of the order in which they appear in the archive, so it only ever hides stuff from earlier layers.

(Fun fact: the spec says that implementations SHOULD generate layers using explicit per-file whiteouts, but MUST accept opaque ones.)

OK, at this point I felt pretty good about my new mental model. And then my brain did the thing it always does.

Wait… what if my file is actually called .wh.foo?

BTW, am I the weird one, or did your brain come up with the same question? 🧠

Anyway… Linux is perfectly happy with a file called .wh.foo:

touch .wh.foo
ls -a
# .  ..  .wh.foo

There’s nothing invalid about that name on a normal Unix filesystem. It’s a hidden file (it starts with a dot) with a slightly odd name. Yes, but it’s still a perfectly valid file, that’s all.

But in an OCI layer, an entry called .wh.foo already means “delete foo from earlier layers”. How would you tell the two apart?

• There’s no flag in the tar entry saying this_is_a_literal_file = true.
• There’s no escaping convention, like .wh.literal.wh.foo.
• There’s no PAX header or extended attribute defined by OCI to distinguish “a regular file named .wh.foo” from “a whiteout for foo”.

So the same bytes can only mean one thing to an OCI consumer. And the spec is very honest about the consequence:

As files prefixed with .wh. are special whiteout markers, it is not possible to create a filesystem which has a file or directory with a name beginning with .wh..

Let me restate that more precisely, because it’s easy to overgeneralise. Linux doesn’t forbid .wh.* names. Your laptop doesn’t care. The limitation belongs to the OCI image layer representation: a serialized OCI image cannot faithfully represent a regular filesystem entry whose name begins with .wh.. The whole .wh.* namespace is effectively reserved:

• .wh.<name> means “delete <name>”;
• .wh..wh..opq means “this directory is opaque”;
• .wh. on its own is invalid.

So yes, saying “these are file names you can’t use in a container image” is a bit of a shorthand. As we are about to discover, these names can exist in some places along the way. They just can’t survive the trip through an OCI layer as regular files.

Of course I had to try it

Reading the spec answered the theoretical question. But now I had another one: what does Docker actually do if you try this?

Does docker build reject the file? Does it silently turn it into a whiteout? Does it escape it somehow? Does the file exist in a later RUN step? And in a container started from the image? What does the layer tar look like? What happens after exporting and re-importing the image? And what about .wh..wh..opq and the invalid .wh.?

At this point, of course, there was only one sensible thing to do: write some Dockerfiles and try to break them.

As the saying goes, “in theory there’s no difference between theory and practice. In practice, there is.” …And, as we’re about to find out, with Docker there can even be a difference between practice and practice after a docker load.

The result is a small repository with a very honest name: lmammino/broken-dockerfile. Its description sums it up: “It works on my machine. Then you push it.” You can go and check it out… Hey, but only after you finish reading here! 🤨

The repository contains a build context with files literally called foo, .wh.foo, .wh..wh..opq, .wh. and c. Each file contains some text naming itself (for example, .wh.foo contains CONTENT-OF-.wh.foo: I am a regular file literally named .wh.foo), so we can always tell what we are looking at. There are four Dockerfiles, one per experiment, and a script that pushes each one through a bunch of different paths:

• a regular docker build, with probes in RUN steps;
• a docker run of the resulting image;
• a docker image save, with a small Python script that lists every entry in the layer tars (type, mode, size, content, PAX headers);
• OCI and filesystem exports via docker buildx;
• and, most importantly, two ways of forcing a fresh unpack of the serialized layers: exporting the image and loading it back with docker image load, and exporting an OCI layout and using it as the base of a new BuildKit build.

To see what’s going on, each Dockerfile has one or more small “probe” steps that list the directory and then check each file of interest:

RUN ls -la /tmp && \
    for p in /tmp/foo /tmp/.wh.foo; do \
      if [ -e "$p" ]; then \
        echo "EXISTS  $p :: $(cat "$p")"; \
      else \
        echo "MISSING $p"; \
      fi; \
    done

The same check also runs inside containers started from the resulting images. So in the outputs below you’ll see lines like these:

EXISTS  /tmp/foo :: CONTENT-OF-foo: I am the regular file named foo
MISSING /tmp/.wh.foo

Printing the content too makes it obvious which file we’re actually looking at. I also run the builds with --progress=plain, so the output of a build step is prefixed by BuildKit’s step number and timing (for example #9 0.117).

I tested this with Docker Engine 29.4.0 and BuildKit (0.29.0 on the default builder, 0.32.2 on a temporary docker-container builder), running on OrbStack on an arm64 Mac, with the overlay2 storage driver and the containerd image store disabled. That last detail matters, and I’ll come back to it. The repository contains the full version matrix, the scripts and all the raw outputs, so you don’t have to take my word for any of this.

Let’s see what happens. 👀

BuildKit says “sure, why not?”

Let’s start with the simplest possible case:

FROM alpine:3.20
COPY .wh.foo /tmp/.wh.foo

Drumroll… the build succeeds. No error. No warning. A later RUN step can see the file, content and all. And if I docker run the image I just built, the file is there:

-rw-r--r--    1 root     root            64 Sep 24 14:19 .wh.foo
EXISTS  /tmp/.wh.foo :: CONTENT-OF-.wh.foo: I am a regular file literally named .wh.foo

So… did we just prove the OCI spec wrong? 🤔

Nope. So far, we have only built the image and run it on the same machine, straight from the files that BuildKit wrote to disk. We haven’t yet forced the image to go through an OCI layer unpack: nothing has taken the serialized layer tars and applied them one by one, following the OCI rules. And that’s exactly what happens when an image travels, for example when you export it and load it somewhere else.

The local snapshot and the layer archive are not quite the same thing

Remember when I said that the tar representation is how layers are serialized, not necessarily how they’re stored locally? This is where that distinction stops being pedantic.

BuildKit doesn’t work with tarballs internally. It works with filesystem snapshots. When it executes COPY .wh.foo /tmp/.wh.foo, it copies a regular file into a snapshot, and nothing about a snapshot cares about .wh. prefixes. So later RUN steps happily see the file.

When I build with the default Docker setup in my environment (overlay2, no containerd image store), the image ends up in overlay2 directories that BuildKit wrote directly. When I then docker run that image, the daemon stacks those directories and starts the container. At no point does anything take a serialized layer tar and apply it according to the OCI rules. Even docker image save reads from those directories and produces tar files: it writes layer tars, but it doesn’t read them back.

So we actually have (at least) two different representations of “the same” layer:

BuildKit snapshot / local overlay2 directories
   → a directory with a regular file called .wh.foo

serialized OCI layer
   → a tar with an entry called tmp/.wh.foo

They are supposed to describe the same thing. For almost every file name in the universe, they do. But for this pathological file name, their meaning can diverge.

I want to be careful here: this is what I observed in my environment. I did not test the containerd image store (which is the default on newer Docker installs), other snapshotters, or other storage drivers, and some of those could well behave differently locally. The part that is not environment-specific is what comes next: what the serialized layer means.

What does the layer tar look like?

Here’s how BuildKit serialized that COPY, as listed by the inspection script (this one is from the second experiment, which we’ll look at in a moment):

== layer 3: created_by: COPY .wh.foo /tmp/.wh.foo # buildkit
  DIR  1777 0:0 size=0    tmp
  REG  0644 0:0 size=64   tmp/.wh.foo   <-- .wh. name
         content: 'CONTENT-OF-.wh.foo: I am a regular file literally named .wh.foo'

Look at that entry closely:

• it’s a plain regular file (REG);
• it has the original mode (0644);
• it has the original content (64 bytes);
• there’s no PAX header, no extended attribute, nothing that says “hey, I’m a literal file, not a whiteout”.

But from the point of view of OCI layer semantics, tmp/.wh.foo is unambiguously a whiteout for tmp/foo. Remember the “whiteouts are empty files” rule I asked you to keep in your back pocket? This one has 64 bytes of content, and (spoiler) the unpackers I tested didn’t care one bit. The name is all that matters.

In other words:

tar interpretation:
  a regular file called tmp/.wh.foo

OCI layer interpretation:
  remove tmp/foo from an earlier layer

Same tar entry. Different semantic layer on top.

BuildKit managed to represent my local filesystem snapshot as tar bytes, but those same bytes acquire whiteout semantics as soon as someone interprets them as an OCI filesystem changeset. I think this is a beautiful example of the difference between a serialization format (tar) and the protocol that interprets it (OCI layer application).

Time to put on the lab coat and do some science! 🧪

Experiment 1: foo and .wh.foo in the same layer

The first Dockerfile copies both files in a single instruction, so they end up in the same layer:

FROM alpine:3.20
COPY foo .wh.foo /tmp/

During the build, and when running the locally built image, both files are there:

EXISTS  /tmp/foo :: CONTENT-OF-foo: I am the regular file named foo
EXISTS  /tmp/.wh.foo :: CONTENT-OF-.wh.foo: I am a regular file literally named .wh.foo

The serialized layer contains both entries, as regular files:

== layer 1: created_by: COPY foo .wh.foo /tmp/ # buildkit
  DIR  1777 0:0 size=0    tmp
  REG  0644 0:0 size=64   tmp/.wh.foo   <-- .wh. name
  REG  0644 0:0 size=48   tmp/foo

Now let’s force a fresh unpack. To do that, I build the image again with a separate BuildKit instance (a docker-container builder), export it straight to a tarball instead of the local Docker image store, and then load that tarball into Docker:

docker buildx build --builder whiteout-test-builder \
  --output type=docker,dest=image.tar \
  -f dockerfiles/exp1-same-layer.Dockerfile -t whiteout-test:exp1 context

docker image load -i image.tar

Since the Docker daemon doesn’t already have the layers created by our COPY, it has no choice but to unpack the serialized layer tars itself. (I also re-imported the image into BuildKit as an OCI layout, which forces a fresh unpack in a different way: check the repo for that one.) This is what we get:

EXISTS  /tmp/foo :: CONTENT-OF-foo: I am the regular file named foo
MISSING /tmp/.wh.foo

.wh.foo is gone, but foo survived! Why?

Because whiteouts only apply to earlier layers. The unpacker saw tmp/.wh.foo, decided it was a whiteout, and (as the spec requires) did not materialise it as a file. But foo was added in the same layer as the whiteout, and a whiteout can’t hide a sibling from its own layer. So foo stays.

So the only casualty was .wh.foo itself: foo survived because it lives in the same layer as the whiteout. But what if foo lived in an earlier layer instead? 😏

Experiment 2: put foo in the previous layer and everything changes

This is the experiment that I consider the real smoking gun.

FROM alpine:3.20
COPY foo /tmp/foo
# (probe step)
COPY .wh.foo /tmp/.wh.foo
# (probe step)

(The probe steps are the ones described earlier; check the repo for the exact Dockerfile.)

This time foo lives in an earlier layer, and .wh.foo comes later. During the build, both files exist:

#9 0.117 EXISTS  /tmp/foo :: CONTENT-OF-foo: I am the regular file named foo
#9 0.118 EXISTS  /tmp/.wh.foo :: CONTENT-OF-.wh.foo: I am a regular file literally named .wh.foo

docker run on the locally built image shows both files too. And if we peek into the overlay2 storage, .wh.foo is sitting there as an ordinary file in the later layer’s directory, while foo lives in the earlier one:

--- .../wkkj2txp7r07grph3iul4ig40/diff/tmp
-rw-r--r--    1 root     root            64 Sep 24 14:19 .wh.foo
--- .../r947zefzt51na5a3xwujcba4w/diff/tmp
-rw-r--r--    1 root     root            48 Sep 24 14:19 foo

Everything looks fine. It works on my machine! ✅

Now let’s force a fresh unpack of the serialized layers, exactly like we did before:

MISSING /tmp/foo
MISSING /tmp/.wh.foo

Both files are gone. 💥

Here’s exactly what happened:

1. the earlier layer added /tmp/foo;
2. the later layer was serialized with a regular tar entry called tmp/.wh.foo;
3. the unpacker (both dockerd and BuildKit, in my tests) interpreted that entry as a whiteout;
4. so it removed /tmp/foo coming from the earlier layer;
5. and, as the spec requires, it did not materialise the whiteout itself;
6. therefore, neither path exists.

Let that sink in for a moment.

A file that I never asked to delete (foo) is gone, deleted by a file that I simply asked to copy.

A filesystem state that BuildKit can represent internally is not necessarily a filesystem state that an OCI layer can faithfully serialize and reconstruct.

“It works on my machine” has rarely been this literal.

But wait, who exports images to tarballs anyway? The way most of us ship images is docker build followed by docker push. So I also tried exactly that: a plain docker build with the default builder, a docker push to a local registry, and then a docker pull + docker run on two brand new Docker daemons (running in docker:dind containers) that had never seen these layers. One of them used the containerd image store (the default on new installs) and the other one the classic overlay2 storage driver.

Same result on both: /tmp/foo and /tmp/.wh.foo are both gone. And the layer stored in the registry contains the very same regular-file entry tmp/.wh.foo that we saw before. So yes, it really works on my machine, then you push it, and it doesn’t work anywhere else. 🙃

Experiment 3: opaque whiteouts, for real

Is this specific to .wh.foo? Let’s try the opaque marker. The earlier layers create a directory with two files:

FROM alpine:3.20
RUN mkdir /tmp/dir && echo lower-a > /tmp/dir/a && echo lower-b > /tmp/dir/b
COPY .wh..wh..opq c /tmp/dir/

During the build (and on the locally built image), the marker is just a regular file and everything is visible:

#9 0.135 -rw-r--r--    1 root     root            74 Sep 24 14:19 .wh..wh..opq
#9 0.135 -rw-r--r--    1 root     root             8 Sep 24 14:24 a
#9 0.135 -rw-r--r--    1 root     root             8 Sep 24 14:24 b
#9 0.135 -rw-r--r--    1 root     root            54 Sep 24 14:19 c

The serialized layer, once again, contains a plain regular-file entry:

== layer 3: created_by: COPY .wh..wh..opq c /tmp/dir/ # buildkit
  DIR  0755 0:0 size=0    tmp/dir
  REG  0644 0:0 size=74   tmp/dir/.wh..wh..opq   <-- .wh. name
  REG  0644 0:0 size=54   tmp/dir/c

And after a fresh unpack:

MISSING /tmp/dir/a
MISSING /tmp/dir/b
EXISTS  /tmp/dir/c :: CONTENT-OF-c: added in the same layer as .wh..wh..opq
MISSING /tmp/dir/.wh..wh..opq

That’s the opaque whiteout doing exactly what the spec says:

• the children inherited from the earlier layer (a and b) are gone;
• c, which came in the same layer as the marker, survives;
• the marker itself is hidden.

So the collision isn’t a quirk of one file name. It’s the whole reserved namespace.

Experiment 4: the .wh. that shouldn’t exist

Finally, the edge case of the edge cases: a file called just .wh., which the spec says is an invalid whiteout.

FROM alpine:3.20
COPY .wh. /tmp/.wh.

BuildKit doesn’t reject it. The build succeeds, the image runs locally, and /tmp/.wh. shows up with its content. The layer tar contains a regular file entry tmp/.wh..

The trouble starts when something tries to unpack that layer. The BuildKit re-import fails, pretty explicitly:

ERROR: failed to build: failed to solve: failed to compute cache key: invalid whiteout name: .wh.: invalid archive

And docker image load fails with a lower-level error:

failed to mknod('/tmp', S_IFCHR, 0): file exists

I won’t try to reverse-engineer that mknod error in detail here (more on character devices in a second), but it looks like the loader tried to turn the whiteout into an overlay whiteout for… the empty name, i.e. the parent directory itself, which already exists. The useful takeaway is simpler: BuildKit let me create a local image that can’t subsequently be consumed as a valid OCI filesystem layer. Build succeeds, export succeeds, load fails.

(If you’re curious, the BuildKit error comes from containerd’s archive package, which checks that the target of a whiteout lives inside the whiteout’s directory. .wh. targets the directory itself, so it fails that check.)

To be fair to BuildKit, the rule that makes .wh. invalid is very fresh. It was only added to the spec in May 2026 (PR #1314), after someone asked in image-spec#1301 what a bare .wh. is supposed to do. Until then, the spec simply didn’t say, and different tools did different things: in that thread, one of the maintainers noticed that umoci treated it as an opaque whiteout! The ink is barely dry on this one.

For extra weirdness: the legacy builder

The repository also runs every experiment with the legacy builder (DOCKER_BUILDKIT=0), which you probably shouldn’t be using in 2026 anyway, but it’s an interesting comparison.

The legacy builder applies whiteout semantics much earlier: at COPY time, during the build itself. So:

• in experiment 1, .wh.foo disappears immediately and foo stays;
• in experiment 2, both foo and .wh.foo are gone already in the next RUN step;
• in experiment 3, a, b and the marker vanish, and c stays;
• in experiment 4, the build fails at the COPY step with the same mknod error we saw before.

The funny part is that docker image save then fails for every one of these images, with errors like:

open .../merged/tmp/.wh.foo: no such file or directory

So the legacy builder produces a filesystem that matches the OCI semantics from the start, but then trips over the missing file when it tries to serialize the image. Different parts of the Docker stack clearly disagree about when these names should acquire their special meaning. The repository has the complete matrix if you want the gory details.

OCI whiteouts are not OverlayFS whiteouts

In experiment 2 with the legacy builder, the overlay2 upper directory contained this:

c---------  0,0  foo

That’s not a .wh.foo file. It’s a character device with device number 0/0, which is how the Linux OverlayFS represents a whiteout on disk (opaque directories, instead, are marked with an extended attribute). That’s also likely why mknod(..., S_IFCHR, 0) showed up in the .wh. error: the loader was translating OCI whiteouts into overlay whiteouts.

This is a good reminder that the .wh.* convention belongs to the OCI layer format. A storage driver is free to represent “this file is deleted” in whatever way its filesystem supports, and translate between the two when importing or exporting layers. The whole mess we’ve seen happens at the boundary between those representations.

Is this a bug?

I’ll admit that naming the repository broken-dockerfile was a bit provocative. So, let’s be fair.

The OCI behaviour is not a bug. It’s explicitly specified. The spec tells you that .wh.* names are whiteouts and that a filesystem containing them can’t be represented. Every unpacker I tested did exactly what the spec says.

Whether BuildKit should reject or warn about literal .wh.* paths before producing an image that can’t round-trip cleanly is a separate question. It’s a tooling and API-design choice, and there may be good reasons (performance, compatibility, “garbage in, garbage out”) for not checking every path.

The limitation itself is well known upstream. It has been discussed since before OCI 1.0: image-spec#24 (“Any chance of changing the whiteout file approach?”), opened in 2016 and still open, points out that with this scheme “base images can no longer contain arbitrary data”. But I couldn’t find any BuildKit issue about rejecting or warning on these names at build time (as of September 2026). And, reading the code, the layer writer that BuildKit uses (again, containerd’s archive package) only generates .wh. names for deletions: added files are written under whatever name they have, with no check. So I don’t want to claim that BuildKit is “broken”. It’s just a case that nothing currently guards against.

The way I’d put it is:

The format is doing exactly what the spec says. The surprising part is that the build pipeline lets us create a state whose serialized meaning is different.

Also, a couple of things I didn’t test, which might be fun follow-ups: building with the containerd image store enabled (I only used it to pull), and creating the file from a RUN step (for example RUN touch /tmp/.wh.foo) rather than with COPY. If you try them, let me know what happens!

So what did we actually learn?

Let’s zoom back out. Here’s what I’m taking home from this rabbit hole.

1. Layers are changesets, not snapshots of the whole filesystem

Each layer only makes sense when applied after the ones that came before it. This is also why extracting a single layer tar somewhere doesn’t give you the filesystem that a container sees (and why just running tar -xf on all of them isn’t enough either: you’d need to apply the whiteouts).

2. Adding and modifying are easy. Deleting is not

Tar already knows how to carry files, directories and their metadata. Additions and modifications are just entries. Deletion is “negative” state, and tar has no concept of it, so OCI had to invent a convention: whiteouts.

“Easy”, though, doesn’t mean “efficient”. A modification isn’t optimised to save bytes in any way: change a single byte in a file, and the new layer contains the entire file again, with that one byte changed. There’s no delta encoding, like the one git uses to pack objects or rsync uses to transfer files. Just a brand new full copy of the file.

3. Deleting doesn’t delete bytes from old layers

A whiteout hides a file from the merged filesystem, but the old layer, and all its bytes, are still part of the image. Same for modifications: a new version of a file doesn’t shrink the old one. This explains a lot of “why is my image so big?” moments.

It’s also why, if you want to delete files to keep your image small (think package manager caches or temporary downloads), you need to do it in the same RUN instruction that creates them:

RUN apt-get update && \
    apt-get install -y curl && \
    rm -rf /var/lib/apt/lists/*

A layer only captures the difference between the filesystem before and after its build step. If a file is created and deleted within the same step, it’s simply not there at the end, so it never makes it into any layer (and no whiteout is needed either). Delete it in the next RUN, instead, and you get a whiteout on top of a layer that still carries all those bytes.

4. .wh.* isn’t just an odd implementation detail

It creates a genuine representational limitation. A perfectly valid Unix filesystem can contain .wh.foo, but an OCI image layer can’t encode it as a regular file, because that name already has protocol-level meaning.

Thankfully, the naming scheme is awkward enough that you’re very unlikely to ever give a real file a name starting with .wh.. At the very least, in over 10 years of using Docker, I have never bumped into an issue caused by this limitation (if you consider one person’s experience a statistically significant sample, that is 😅).

5. The builder’s internal state and the serialized image can differ

This was the most surprising discovery for me. In the setup I tested, BuildKit’s snapshots (and the local image built from them) can contain states that the OCI layer format simply cannot round-trip. Everything works locally, and then the image means something different somewhere else.

6. Formats inherit the compromises of what they’re built on

This is probably the most important takeaway from a systems design perspective. Tar was a pragmatic foundation. Whiteouts are the extra convention that lets a tar-based changeset express something tar itself was never designed to express. And conventions like that tend to have sharp edges in the corners.

Sure, whiteouts could have been built on PAX headers instead (as proposed back in 2016), which would arguably have been a better fit: a PAX record lives in the entry’s metadata, so it wouldn’t reserve any file names. But either way, it would still be a convention layered on top of tar, a workaround for something tar simply can’t express on its own.

Whenever you reuse an existing format for a purpose it wasn’t designed for, you’ll probably need to add conventions on top of it, and every convention you add eventually reserves some part of the input space. So it’s worth asking early: what can my users no longer express?

The cheat sheet

Here’s the whole thing in one table:

So, is it a hack?

I promised you we’d come back to this.

On one hand: yes, it’s a little hacky. Reserving magic file names leaks a protocol convention into what otherwise looks like an ordinary filesystem namespace. A layer entry doesn’t mean what tar says it means, and you only find out if you know the rules. And it produces funny edge cases, like the ones we just saw, where an innocent COPY deletes a different file, but only after the image travels somewhere else.

And it turns out I’m not the only one who thinks so. At the beginning of this article, I said that my take on tar and whiteouts was just an intuition. Well, image-spec#24 gave me some actual history: according to people involved in the spec, the .wh. scheme was inherited from AUFS, the union filesystem early Docker was built on. As one of the maintainers put it: “the original image code was just based on how AUFS did things because AUFS was the only real union filesystem at the time”. Another one was even more blunt: “The .wh. is a silly approach.”

On the other hand: it’s also extremely pragmatic, and I’d go as far as calling it elegant. OCI keeps using plain, standard tar archives. Any tool that can read tar can read a layer. Generating a layer is just writing a tar. And with one tiny naming convention, you get deletion semantics without inventing a brand new archive format and all the tooling that would come with it. The price is that you can’t have files starting with .wh. in your images, which… let’s be honest, is a price very few people will ever notice. (Again, if you consider me a statistically valid sample: it took me over 10 years to find out, and not because of an actual bug, but because I accidentally started reading the spec!)

That’s pretty much the argument that won in that same thread: “Is there a realistic use case for distributing .wh. files, other than packing up a container runtime into an image?”, followed by the observation that there are already “millions of container images using this approach”. Changing it would mean every implementation having to support two formats forever, just to unlock a handful of weird file names.

Personally, I lean towards: it feels hacky, but I really admire how simple and practical it is. Boring technology, plus a little bit of protocol glue.

Wrapping up

All of this started because I was trying to understand SOCI. I went looking for answers about lazy-loading compressed container layers, and somehow ended up learning about magic .wh.* files and building a repository full of intentionally broken Dockerfiles. Pretty standard rabbit-hole-driven development, I suppose. (And yes, the SOCI stuff is coming, keep an eye on AWS Bites!)

I started with what felt like a fairly mundane question: “how does Docker delete a file?”. The answer turned out to involve magic file names, opaque directories, an entire reserved namespace of file names, and a Docker image that changes its filesystem after being exported and imported again. Not bad for one innocent question!

If I had to condense everything into a mental model, it would be this: layers aren’t miniature filesystems. They are ordered filesystem changesets. The filesystem a container sees is what you get after interpreting all those changesets, in order, following the OCI rules. Additions and modifications are plain tar entries, deletions are whiteouts, and that convention means that a regular file whose name starts with .wh. can’t survive the round trip through an OCI image.

I still think tar was a brilliant choice. It’s simple, boring, ubiquitous technology, and boring technology tends to survive. Whiteouts are the little bit of protocol glue needed to stretch it beyond what tar knows how to express on its own.

Now I’m curious to hear from you:

• Did you already know about whiteouts? If so, congratulations, you were several layers ahead of me! 😄
• Do you know why BuildKit lets these names through without complaining?
• Have you run into other weird consequences of how OCI layers work?
• And the big one: elegant bit of Unix pragmatism or a hack we’ve all learned to live with? Feel free to disagree with me!

You can find me on Bluesky, and the full experiment (with all the scripts, logs and version details) is on GitHub at lmammino/broken-dockerfile. PRs with more cursed experiments are very welcome. 🐇

Further reading

• OCI Image Specification: Image Layer Filesystem Changeset: the source of truth for everything about changesets and whiteouts.
• Docker docs: storage drivers and the overlay2 driver.
• Linux kernel docs: Overlay Filesystem, if you want to see how whiteouts and opaque directories work at the filesystem level.
• SOCI snapshotter: the thing that started this whole rabbit hole.
